Half-wave rectifier / bridge rectifier
Reference number A
mm
B
mm
C
mm
D
mm
E
mm
1001440 34 30 25 3.5 4.5
1001441 64 30 54 4.5 5
1 2 3 4 5 6
54
9
9
30
5
4.5
12 34 65
48.6
4.5
54
5.6
15
64 17.5
Phase rectifier (reference number 1001442)
Mounting rail 35 mm EN 50022 Mayr
part no. 1802911
Brake rectifier dimensions
