Interroll Drum motor series i, S, S/A, D
S/A-series product information
48
Version 4.1 (06/2015) en-US
Translation of original instruction manual
10 Rated current 27 Insulation class and IP rating
11 (rated current)
1)
28 Circumferential speed of tube
12 Rated speed of rotor
1)
29 Oil type
13 Power factor 30 Brake data
14 Run capacitor 31 Date of manufacture (week/year/country)
15 Type 32 Encoder data
16 Part number 33 Permissible ambient temperature
17 Customer part number
1)
The value depends on the voltage used. All values in parentheses refer to the rated voltage in
parentheses.
Electrical data of S/A-series
Abbreviations See "List of abbreviations", page 108
P
N
n
P
n
N
f
N
U
N
I
N
cosφ
η
J
R
I
S
/I
N
M
S
/
M
N
M
B
/
M
N
M
P
/
M
N
M
N
R
M
C
r
kW min
-1
Hz W A kgcm
2
Nm
Ω
µF
0.25 4 1360 60 115 4.34 0.95 0.53 7.2 2.07 1.31 1.31 1.31 1.76 0 40
0.25 4 1360 50 230 2.4 0.97 0.47 7.2 1.25 1.1 1.1 1.1 1.76 12.7 12
P
N
n
P
n
N
f
N
U
N
I
N
cosφ
η
J
R
I
S
/I
N
M
S
/
M
N
M
B
/
M
N
M
P
/
M
N
M
N
R
M
U
SH delta
U
SH star
C
r
kW min
-1
Hz W A kgcm
2
Nm
Ω
V DC V DC µF
0.37 4 1400 50 230 2.1 0.71 0.63 7.4 3.9 2.24 2.24 2.24 2.52 21.4 16 - -
0.37 4 1700 60 230 1.7 0.78 0.54 7.4 4.8 2.67 2.67 2.67 2.08 21.4 14 - 19
0.37 4 1360 60 330 1.54 0.66 0.69 7.4 3.9 2.24 2.24 2.24 2.6 34 - 17 11
0.37 4 1400 50 400 1.2 0.71 0.63 7.4 3.9 2.24 2.24 2.24 2.52 21.4 - 27 -
0.37 4 1700 60 460 1.1 0.78 0.54 7.4 4.8 2.67 2.67 2.67 2.08 21.4 - 28 19
0.37 4 1360 60 575 0.82 0.66 0.69 7.4 3.9 2.24 2.24 2.24 2.6 34 - 28 11
113S/A 1-phase
113S/A 3-phase
