Interroll i Series User Manual

Interroll Drum motor series i, S, S/A, D
S-series product information
Version 4.1 (06/2015) en-US
Translation of original instruction manual
41
P
N
n
P
n
N
f
N
U
N
I
N
cosφ
η
J
R
I
S
/I
N
M
S
/
M
N
M
B
/
M
N
M
P
/
M
N
M
N
R
M
U
SH delta
U
SH star
C
r
kW min
-1
Hz W A kgcm
2
Nm
Ω
V DC V DC µF
0.16 4 1350 50 400 0.57 0.75 0.54 3.3 3.98 3.25 3.35 3.25 1.13 59.2 - 38 14
0.16 4 1665 60 460 0.52 0.78 0.5 3.9 1.8 2.09 2.09 2.09 0.92 64.1 - 39 9
0.16 4 1610 60 230 1 0.76 0.53 3.3 4.28 3.07 2.99 3.07 0.95 59.2 - - 12
0.16 4 1672 60 460 0.55 0.75 0.49 3.3 4.86 4.27 4.15 4.27 0.91 59.2 - 37 10
0.18 4 1383 50 230 0.98 0.76 0.55 5.6 3.71 1.76 2.08 1.76 1.24 47 18 - 15
0.18 4 1384 50 230 1 0.76 0.59 4 4 2.73 2.9 2.73 1.24 15 - - 14
0.18 4 1384 50 400 0.62 0.76 0.55 4 3.71 3.13 3.27 3.13 1.24 47 - 33 15
0.18 4 1383 50 400 0.62 0.76 0.55 5.6 3.71 1.76 2.08 1.76 1.24 47 - 33 15
0.18 4 1355 50 230 1 0.77 0.59 4 4.37 3.54 3.74 3.54 1.27 45.5 - - 14
0.18 4 1355 50 400 0.62 0.76 0.55 4 4.42 3.6 3.79 3.6 1.27 45.5 - 32 15
0.18 4 1665 60 575 0.47 0.73 0.53 4 3.91 3.23 3.15 3.23 1.03 88.5 - 46 6.5
0.18 4 1620 60 230 1.08 0.77 0.54 4 4.59
3.44 3.27 3.44 1.06 45.5 - - 12
0.18 4 1675 60 460 0.62 0.76 0.48 4 5.22 4.76 4.54 4.76 1.03 45.5 - 32 11
0.33 2 2800 50 230 1.74 0.76 0.68 3.3 4.5 3.57 3.57 2.62 1.13 21.5 14 - -
0.33 2 3420 60 230 1.43 0.73 0.68 3.3 4.5 3.2 3.2 3.2 0.92 21.5 11 - -
0.33 2 2800 50 400 0.93 0.76 0.68 3.3 4.5 3.57 3.57 2.62 1.13 21.5 - 23 -
0.33 2 3420 60 460 0.83 0.73 0.68 3.3 4.5 3.2 3.2 3.2 0.92 21.5 - 20 -
