Interroll Drum motor series i, S, S/A, D
S-series product information
Version 4.1 (06/2015) en-US
Translation of original instruction manual
43
Type A
mm
B
mm
C
mm
D
mm
E
mm
F
mm
H
mm
FW
mm
EL
mm
AGL
mm
80S cylindrical, stainless steel,
outside untreated
SL 603 to 952 mm
83 83 20 35 45 21 8 SL+10 SL+16 SL+56
113S cambered 113.3 112.4 20 35 45 21 14 SL+22 SL+28 SL+68
113S cylindrical 113.0 113.0 20 35 45 21 14 SL+22 SL+28 SL+68
