Version 3.0 (04/2013) en
Translation of the original instructions
RollerDrive EC100 / EC110
Product information
RollerDrive label
The specifications on the RollerDrive label are used to identify the RollerDrive.
This is required to use the RollerDrive as intended.
Product identification
To identify a RollerDrive, the following information is required. You may enter the
values of your RollerDrive in the last column.
Type plate
1 Manufacturer
2 Date of production
3 Gear ratio
4 Performance
5 Nominal voltage
6 Speed range
7 Type of RollerDrive
8 Serial number
I
N
T
E
R
R
O
L
L
R
o
l
l
e
r
D
r
i
v
e
03/10
9:1
11 W
24 VDC
0,04 –
0,90 m/s
BT 100
123456789
I
n
t
e
r
r
o
l
l
E
n
g
i
n
e
e
r
i
n
g
G
m
b
H
/
D
6
7
8
G
a
Information Possible value Own value
RollerDrive label Motor type
Gear ratio
Serial number
Tube diameter 50 mm or 1.9 in
Tube material Zinc-plated, galvanized,
aluminum or stainless steel
(with or without sleeves)
Roller length EL/BF
Roller transmission Torque transmission
Idler cartridge shaft Spring loaded or floating
(see "Dimensions of bearing
seats on the non-driven side",
page 13)
