Interroll RollerDrive EC100 User Manual

10
Version 3.0 (04/2013) en
Translation of the original instructions
RollerDrive EC100 / EC110
Product information
Performance data of the RollerDrive EC100 with DriveControl
Performance data of RollerDrive EC110 with DriveControl
HC-EC110
Gear ratio Rated torque
(1.8 A)
Start-up torque
with DriveControl DC-
EC100
(4.1 A)
Start-up torque
with DriveControl HC-
EC100
(4.1 A)
1)
Maximum speed
12:1 0.37 Nm
(3.3 in-lbf)
1.0 Nm
(8.9 in-lbf)
1.4 Nm
(12 in-lbf)
1.32 m/s
(260 fpm)
16:1 0.48 Nm
(4.2 in-lbf)
1.5 Nm
(13.3 in-lbf)
1.8 Nm
(16 in-lbf)
1.03 m/s
(202 fpm)
24:1 0.75 Nm
(6.6 in-lbf)
2.2 Nm
(19.5 in-lbf)
2.8 Nm
(25 in-lbf)
0.69 m/s
(135 fpm)
36:1 1.17 Nm
(10.4 in-lbf)
3.0 Nm
(26.6 in-lbf)
3.8 Nm
(34 in-lbf)
0.44 m/s
(88 fpm)
48:1 1.24 Nm
(11.0 in-lbf)
4.0 Nm
(35.4 in-lbf)
5Nm
(44 in-lbf)
0.35 m/s
(68 fpm)
64:1 1.82 Nm
(16.1 in-lbf)
5.2 Nm
(46.0 in-lbf)
6.1 Nm
(54 in-lbf)
0.25 m/s
(50 fpm)
96:1 3.00 Nm
(26.6 in-lbf)
9.8 Nm
(86.7 in-lbf)
11.3 Nm
(100 in-lbf)
0.17 m/s
(34 fpm)
1)
The HC-EC100 provides higher peak torque. Nominal torque is similar to the DC-EC100.
Maximum static load per roller not more than 40 kg (88 lb).
Gear ratio Rated torque
(2.5 A)
Start-up torque
(4.1 A)
Maximum speed
4:1 0.34 Nm
(3 in-lbf)
1.2 Nm
(11 in-lbf)
2.41 m/s
(475 fpm)
9:1 0.75 Nm
(6.6 in-lbf)
2.6 Nm
(23 in-lbf)
1.07 m/s
(211 fpm)
12:1 1.0 Nm
(8.8 in-lbf)
3.5 Nm
(31 in-lbf)
0.8 m/s
(158 fpm)
16:1 1.5 Nm
(13 in-lbf)
4.2 Nm
(37 in-lbf)
0.6 m/s
(119 fpm)
24:1 2.2 Nm
(19.5 in-lbf)
5.8 Nm
(51 in-lbf)
0.4 m/s
(79 fpm)
36:1 3.0 Nm
(26.5 in-lbf)
9.2 Nm
(81 in-lbf)
0.27 m/s
(53 fpm)
48:1 3.4 Nm
(30 in-lbf)
11.5 Nm
(102 in-lbf)
0.2 m/s
(40 fpm)
64:1 4.25 Nm
(37.6 in-lbf)
13.2 Nm
(117 in-lbf)
0.15 m/s
(30 fpm)
1)
Maximum static load per Roller not more than 40 kg (88 lb). The information refers to continuous operation under
maximum load (S1 operation).
