RollerDrive EC100 / EC110
Assembly
Warning information for assembly
Do not drop or mishandle the RollerDrive to avoid internal damage.
Check each RollerDrive visually for damage before assembly.
In order to prevent damage to the internal connections, do not hold, carry or
secure the RollerDrive by the motor cable.
Do not force the RollerDrive when inserting it into the conveyor frame. It
should fit easily into the holes in the frame.
Ensure that the proper tightening torque is applied to the RollerDrive hex nut
to prevent the shaft spinning in the frame and the wires twisting (see
"Securing the RollerDrive in the conveyor frame", page 21).
Do not twist the motor cable.
Rotating parts
Risk of pinched fingers
Do not insert fingers between the RollerDrive and the
round belt, PolyVee belt or roller chain.
Install a protection device (such as a guard plate) to
prevent fingers from getting trapped in the round belt,
PolyVee belt or roller chain.
Install an appropriate warning on the conveyor.
Risk of damage leading to failure or shortened life
expectancy of the RollerDrive
Follow the instructions below.
