28
Version 3.0 (04/2013) en
Translation of the original instructions
RollerDrive EC100 / EC110
Appendix
Accessories
Belt
DriveControls
Anti-spin bracket
Part Description
Toothed belt • Gates Poly-Chain GT or similar: pitch 8 mm (0.31 in)
• Toothed belt width: 11.2 mm (11.18 mm)
• Hub with 18 teeth
Round belt • Belts of 4 mm (0.16 in) and max. 5 mm (0.20 in)
diameter
PolyVee belt • Drive head with 9 grooves for flexible V-ribbed belts
• PJ form, ISO 9981, DIN 7867
• pitch 2.34 mm (2.29 mm)
• Belts with a max. of 4 ribs
Part Description Part #
DC-EC100 Motor control card (without ZPA functionality) 8996
HC-EC100 HybridControl with ZPA and motor control on
one board, but can be used separately
9000
HC-EC100 Full HybridControl with ZPA, motor control and
digital I/O handshake
9001
HC-EC110 HybridControl with ZPA and motor control on
one board, but can be used separately
9004
Part Description Part #
Anti-spin bracket flat up Bottom and top of hex are flat N582
Anti-spin bracket point up Bottom and top of hex are pointed N583
