RollerDrive EC100 / EC110
Product information
Technical specifications
RollerDrive EC100 EC110
Rated voltage 24 VDC 24 VDC
Voltage range 22 to 28 VDC 22 to 28 VDC
Idle current 0.6 A 0.6 A
Maximum continuous current 1.8 A 2.5 A
Maximum peak current 4.1 A 4.1 A
Mechanical power 18 W 31 W
System efficiency (drive) 42% 52%
Maximum ripple from power supply 5% 5%
Noise emission (mounted) 55 dB(A) 55 dB(A)
Protection classification IP54 IP54
Ambient temperature in operation 0 °C to 40 °C (32 °F to 104 °F)
Ambient temperature during transport
and storage
-20 °C to 75 °C (-4 °F to 167 °F)
Temperature changes max. 1 °K/min; 3 h; two cycles in acc.
with IEC 68-2-14
Air humidity max. 90% not condensing
Installation height above sea level max. 1000 m (max. 3300 ft)
Hint
Mechanical performance, performance data and performance charts are on basis
of 20 °C (68 °F).
