34 | Optidrive P2 User Guide | Version 3.00 www.invertekdrives.com
5.8. Keypad Short Cuts
The following short cuts can be used to speed up selecting and changing parameters when using the keypad.
5.8.1. Selecting the Parameter Groups
When extended or advanced parameter access is enabled (see section 8. Extended Parameters on page 44), additional
parameter groups are visible, and may be selected quickly by the following method.
 
Whilst in the parameter selection menu,
press the Navigate and Up or Navigate
and Down keys simultaneously.
The next highest or lowest
accessible parameter group will be
selected.
5.8.2. Selecting the Lowest Parameter in a Group
 
Whilst in the parameter selection
menu, press the Up and Down keys
simultaneously.
The next highest or lowest
accessible parameter group will be
selected.
5.8.3. Setting a Parameter to the Minimum Value
 
Whilst editing a parameter
value, press the Up and Down
keys simultaneously.
The parameter will be set to
the lowest possible value.
5.8.4. Adjusting Individual Digits
When editing parameter values and making large changes, e.g. setting the motor rated speed from 0 to 1500RPM, it is possible to
directly select the parameter digits using the following method.
     
Whilst editing a
parameter value, press
the Stop and Navigate
keys simultaneously.
The cursor will step
one digit to the left.
Repeating the key
press will move
another digit to the
left.
The individual digit
value may be
adjusted using the up
and down keys.
Adjust the value using
the Up and Down
keys
When the cursor reaches
the highest accessible
digit, pressing Stop and
Navigate will return the
cursor to the right most
digit.
Press the Navigate
key to return to the
parameter selection
menu.
5
