Technical Data
10. Technical Data
10.1. Environmental
Ambient
Temperature
Storage and Transportation All Units -40 … 60°C / -40 … 140°F
Operating IP20 Units -10 … 50°C / 14 … 122°F
IP55 Units - 10 … 40°C / 14 … 104°F UL Approved
40 … 50°C / 104 … 122°F With derating (refer to section 10.4.1. Derating for
Ambient Temperature on page 72)
IP66 Units - 10 … 40°C / 14 … 104°F UL Approved
40 … 50°C / 104 … 122°F With derating (refer to section 10.4.1. Derating for
Ambient Temperature on page 72)
Altitude Operating All Units =<1000m With UL approval
=<4000m With derating (refer to section 10.4.2. Derating for
Altitude on page 72)
Relative Humidity Operating All Units < 95% Non-condensing, frost and moisture free
10.2. Input/Output Power and Current Ratings
The following tables provide the output current rating information for the various Optidrive P2 models. Invertek Drives always
recommend that selection of the correct Optidrive is based upon the motor full load current at the incoming supply voltage.
10.2.1. 200 – 240 Volt (+/- 10%),1 Phase Input, 3 Phase Output
Frame
Size
Power
Rating
Input
Current
Fuse or MCB
(Type B)
Maximum Cable
Size
Rated
Output
Current
Maximum
Motor Cable
Length
Recommended
Brake
Resistance
kW HP A Non UL UL mm AWG/kcmil A m ft Ω
2 0. 75 1 8.5 10 15 8 8 4.3 100 330 10 0
2 1.5 1.5 15 . 2 25 20 8 8 7 100 330 50
2 2.2 1.5 19. 5 25 25 8 8 10.5 10 0 330 35
NOTE
Ratings shown above apply to 40°C Ambient temperature. For derating information, refer to section 10.4.1.
 The maximum motor cable length stated applies to using a shielded motor cable. When using an unshielded cable, the maximum
cable length limit may be increased by 50%. When using the Invertek Drives recommended output choke, the maximum cable
length may be increased by 100%.
 The PWM output switching from any inverter when used with a long motor cable length can cause an increase in the voltage at the
motor terminals, depending on the motor cable length and inductance. The rise time and peak voltage can affect the service life of
the motor. Invertek Drives recommend using an output choke for motor cable lengths of 50m or more to ensure good motor service
life.
 For UL compliant installation, use Copper wire with a minimum insulation temperature rating of 70°C, UL Class CC or Class J
Fuses.
