56 | Optidrive P2 User Guide | Version 3.00 www.invertekdrives.com
8.4. Advanced Parameters
For Advanced Parameters, basic information only is provided in this guide. The parameter functions are described more fully in
Optitools Studio PC software.
8.4.1. Parameter Group 6 – Advanced Configuration
Par. Function Setting Range Default Notes
P6-01 Enable Firmware Upgrade
0 Disabled
0 This parameter should not be
adjusted by the user.
1 I/O and DSP Upgrade
2 I/O Upgrade
3 DSP Upgrade
P6-02 Minimum Effective Switching Frequency 4 – 32kHz (Model Dependent) 4 kHz
P6-03 Auto Reset Time Delay 1 – 60 Seconds 20s
P6-04 Relay Output Hysteresis 0.0 – 25.0% 0.3%
P6-05 Function Block Program Enable 0 Disabled 0
1 Enabled
P6-06 Encoder PPR 0 - 65535 0
P6-07 Speed Error Trip Threshold 0.0 – 100.0% 5.0%
P6-08 Maximum Speed Reference Frequency 0 – 20kHz 0 kHz
P6-09 Speed Droop Control 0.0 – 25.0% 0.0%
P6-10 Function Block Program Enable 0 Disabled 0
1 Enabled
P6-11 Speed Hold Time on Enable 0 – 250s 0s
P6-12 Speed Hold / DC Injection Time on Disable 0 – 250s 0s
P6-13 Hoist Mode : Brake Release Time 0.0 – 5.0s 0.2s
P6-14 Hoist Mode : Brake Apply Time 0.0 – 5.0s 0.3s
P6-15 Hoist Mode : Pre-Torque Level 0.0 – 200.0% 8.0%
P6-16 Hoist Mode : Pre-Torque Timeout 0.0 – 25.0s 5.0s
P6-17 Torque Limit Trip Time 0.0 – 25.0s 0.0s
P6-18 DC Injection Current 0.0 – 100.0% 0.0%
P6-19 Brake Resistor Resistance Model Dependent
P6-20 Brake Resistor Power Model Dependent
P6-21 Brake Chopper Under Temperature Duty Cycle 0.0 – 20.0% 2.0%
P6-22 Reset Fan Run Time 0 No Reset 0
1 Reset
P6-23 Reset Energy Meters 0 No Reset 0
1 Reset
P6-24 Maintenance Time Interval 0 – 60000 Hours 0 Hours
P6-25 Reset Maintenance Time 0 No Reset 0
1 Reset
P6-26 Analog Output 1 Scaling 0.0 – 500.0% 100.0%
P6-27
Analog Output 1 Offset
-500.0 – 500.0% 0.0%
P6-28 P0-80 Display Value 0 - 255 0
P6-29 Save User Parameters 0 No Function 0
1 Save Parameters
2 Clear Parameters
P6-30 Advanced Access Code 0 – 9999 2 01
8
