Version 3.00 | Optidrive P2 User Guide | 59www.invertekdrives.com
8.5. Parameter Group 0 – Monitoring Parameters (Read Only)
Par. Function Units
P0-01 Analog Input 1 Scaled Signal Level %
P0-02 Analog Input 2 Scaled Signal Level %
P0-03 Digital Input Status – Bit representation (0 or 1) where the left most digit indicates the status of Digital Input 1 N/A
P0-04 Pre-Ramp Speed Reference Hz / RPM
P0-05 Torque Reference / Limit %
P0-06 Digital (Keypad) Speed Reference Hz / RPM
P0-07 Fieldbus Speed Reference Hz / RPM
P0-08 PID Reference (Setpoint) %
P0-09 PID Feedback %
P0-10 PID Output %
P0-11 Applied Motor Voltage V
P0-12 Output Torque %
P0-13 Trip Log – Last 4 Trips N/A
P0-14 Motor Magnetising Current Id A
P0-15 Motor Rotor Current Iq A
P0-16 DC Voltage Ripple V
P0-17 Motor Stator Resistance Rs Ω
P0-18 Motor Stator Inductance Ls H
P0-19 Motor Rotor Resistance Rr Ω
P0-20 DC Bus Voltage V
P0-21 Drive Temperature °C
P0-22 Remaining Service Time Hours
P0-23 Operating Time Heatsink > 85→C HH:MM:SS
P0-24 Operating Time High Ambient Temperature HH:MM:SS
P0-25 Rotor Speed Hz / RPM
P0-26 Energy consumption kWh kWh
P0-27 Energy Consumption MWh MWh
P0-28 Drive firmware version N/A
P0-29 Drive Type N/A
P0-30 Drive serial number N/A
P0-31 Drive Lifetime HH:MM:SS
P0-32 Run time since last trip 1 HH:MM:SS
P0-33 Run time since last trip HH:MM:SS
P0-34 Last operating time HH:MM:SS
P0-35 Cooling fan operating time Hours
P0-36 DC Bus Voltage Log: 8 samples, 256ms V
P0-37 DC Bus Ripple Log: 8 samples 20ms V
P0-38 Heatsink Temperature Log: 8 samples, 30s °C
P0-39 Ambient temperature log: 8 samples, 30s °C
P0-40 Motor Current Log: 8 samples 256ms A
P0-41 Over current trip count N/A
P0-42 Over voltage trip count N/A
P0-43 Under voltage trip count N/A
P0-44 Over temperature trip count N/A
P0-45 Brake resistor over current trip count N/A
8
Extended Parameters
