8.4.4. Parameter Group 9 – User Inputs and Output Programming
Par. Function Setting Range Default Notes
P9-01 Enable Input Source These parameters allow the user to directly select the source of the various command points.
Parameters are only adjustable if P1-13 = 0. This allows complete flexibility over the drive
control functions, and interaction with the internal Function Block programming environment.
P9-02 Fast Stop Source
P9-03 Run Forward Source
P9-04 Run Reverse Source
P9-05 Latch Enable 0 Disabled 0
1 Enabled
P9-06 Reverse Input Source See above
P9-07 Reset Source
P9-08 External Trip Source
P9-09 Terminal Control Override Source
P9-10 Speed Setpoint 1 In combination with P9-18 – P9-20, allow selection of several speed reference sourcesfor
common applications.
P9-11 Speed Setpoint 2
P9-12 Speed Setpoint 3
P9-13 Speed Setpoint 4
P9-14 Speed Setpoint 5
P9-15 Speed setpoint 6
P9-16 Speed Setpoint 7
P9-17 Speed Setpoint 8
P9-18 Reference Select Bit 0 See above
P9-19 Reference Select Bit 1
P9-20 Reference Select Bit 2
P9-21 Preset Speed Select Bit 0
P9-22 Preset Speed Select Bit 1
P9-23 Preset Speed Select Bit 2
P9-24 Acceleration Ramp Select Bit 0
P9-25 Acceleration Ramp Select Bit 1
P9-26 Deceleration Ramp Bit 0
P9-27 Deceleration Ramp Bit 1
P9-28 MOP Up Source
P9-29 MOP Down Source
P9-30 Speed Limit Switch Forward
P9-31 Speed Limit Switch Reverse
P9-33 Analog Output 1 Control 0 P2-11 0 These parameters allow the user to overdide
the normal parameter control source for the
associated function, allowing interaction with the
internal Function Block programming environment.
1 Function Block Digital
2 Function Block Analog
P9-34 Analog Output 2 Control 0 P2-13 0
1 Function Block Digital
2 Function Block Analog
P9-35 Relay 1 Control 0 P2-15 0
1 Function Block Digital
P9-36 Relay 2 Control 0 P2-18 0
1 Function Block Digital
P9-37 Display Scaling Control 0 P2-21 0
1 Function Block Digital
P9-38 PID Setpoint Control 0 P3-05 0
1 Function Block Digital
P9-39 PID Feedback Control 0 P3-10 0
1 Function Block Digital
P9-40 Torque Reference Control 0 P4-06 0
1 Function Block Digital
P9-41 Relay 3, 4 and 5 Control 0 Default Settings 0
1 Function Block Digital
