Version 3.00 | Optidrive P2 User Guide | 7www.invertekdrives.com
2
General Information & Ratings
2.2. Product Rating Label Location
All Optidrive P2 models carry a rating label, which can be located as follows:
IP20 Models IP55 Models IP66 Models
On right hand side when viewed from the
front.
On right hand side when viewed from the
front.
On the top surface.
2.3. Understanding the Rating Label
The product rating label provides the following information.
Key
1 Model Code
2 Enclosure Type and IP Rating
3 Firmware Version
4 Serial Number
5 Technical Data – Supply Voltage
6 Technical Data – Maximum continuous
output current
