40 | Optidrive P2 User Guide | Version 3.00 www.invertekdrives.com
7.2. Digital Input Configuration Parameter P1-13
P1-13 DI1 DI2 DI3 AI1 / DI4 AI2 / DI5
State 0 1 0 1 0 1 0 1 0 1
0 User defined
1 STOP RUN
FWD REV
P1-12 REF P - 21 Analog Input AI1 P2-01 P2-02
2 STOP RUN
FWD REV
DI3 DI4 DI5 Preset Speed
0 0 0 P2-01 REF
1 0 0 P2-02 REF
0 1 0 P2-03 REF
1 1 0 P2-04 REF
0 0 1 P2-05 REF
1 0 1 P2-06 REF
0 1 1 P2-07 REF
1 1 1 P2-08 REF
3 STOP RUN
FWD REV
P1-12 REF P2-01 REF Analog Input AI1 Analog Input AI2
4 STOP RUN
FWD REV
P1-12 REF P2-01 REF Analog Input AI1 DECEL P1-04 DECEL P8-11
5 STOP RUN
FWD REV
P1-12 REF AI2 REF Analog Input AI1 Analog Input AI2
6 STOP RUN
FWD REV
P1-12 REF P2-01 REF Analog Input AI1 E-TRIP OK
7 STOP RUN
FWD REV
DI3 DI4 Preset Speed E-TRIP OK
Off Off P2-01 REF
On Off P2-02 REF
Off On P2-03 REF
On On P2-04 REF
8 STOP RUN
FWD REV
DI3 DI4 Preset Speed DECEL P1-04 DECEL P8-11
Off Off P2-01 REF
On Off P2-02 REF
Off On P2-03 REF
On On P2-04 REF
8 STOP RUN
FWD REV
DI3 DI4 Preset Speed P1-12 REF PR-REF
Off Off P2-01 REF
On Off P2-02 REF
Off On P2-03 REF
On On P2-04 REF
10 STOP RUN
FWD REV
(NO)
INC SPD
(NO)
DEC SPD
P1-12 REF
1
P2-01-REF
11 STOP
RUN FWD
STOP
RUN REV
P1-12 REF PR-REF Analog Input AI1 P2-01 REF P2-02 REF
12 STOP
RUN FWD
STOP
RUN REV
DI3 DI4 DI5 Preset Speed
Off Off Off P2-01 REF
On Off Off P2-02 REF
Off On Off P2-03 REF
On On Off P2-04 REF
Off Off On P2-05 REF
On Off On P2-06 REF
Off On On P2-07 REF
On On On P2-08 REF
13 STOP
RUN FWD
STOP
RUN REV
P1-12 REF P2-01 REF Analog Input AI1 Analog Input AI2
14 STOP
RUN FWD
STOP
RUN REV
P1-12 REF P2-01 REF Analog Input AI1 DECEL P1-04 DECEL P8-11
15 STOP
RUN FWD
STOP
RUN REV
P1-12 REF AI2-REF Analog Input AI1 Analog Input AI2
16 STOP
RUN FWD
STOP
RUN REV
P1-12 REF P2-01 REF Analog Input AI1 E-TRIP OK
7
Control Terminal Functions
