CHV180 series frequency inverter special for elevator Communication protocol
.101.
The data address of control and state parameters please refer to the following table.
Parameter Description
Address
Meaning of value
R/W
Feature
Control command 1000H
0001H: Up running
W/R
0002H: Down running
0003H: Up running overhaul
0004H: Down running overhaul
0005H: Stop
0006H: Coast to stop
0007H: Reset fault
0008H: overhauling ceased
Inverter state 1001H
0001H: Up running
R
0002H: Down running
0003H: Standby
0004H: Fault
Communication setting 2000H
Communication Setting Range
(-10000~10000)
Note: the communication setting
is the percentage of the relative
value (-100.00%~100.00%). If
it is set as frequency source, the
value is the percentage of the
maximum frequency (P0.04).
W/R
Virtual terminal input
function setting
2001H Reserved W/R
State parameters
3000H Output speed R
3001H Reference speed R
3002H DC Bus voltage R
3003H Output voltage R
3004H Output current R
3005H Running frequency R
3006H Rotation speed R
3007H Output power R
3008H Output torque R
