CHV180 series frequency inverter special for elevator Appendix A
.114.
(MS1~MS3), delay the time of T1, the inverter output actuate control command
to contactor。
 After T2, when the inverter received the feedback signal of contactor. It is
running at 0 speed, and output Y1 at the same time. After T3, the inverter output
contracting brake close signal (FC).
 After T4, the inverter received the feedback signal of contracting brake, after
affirming it is open completely, the inverter is accelerated running with S-curve.
 After the speed command (MS1~MS3) is cut off, the inverter is decelerated
stopping with S-curve. When the speed reaches P8.13 (Stop contracting brake
frequency), the inverter output the brake open command (FC) after T5 for cutting
off running command.
 After T6, when it receives the stop command, and after T7, the inverter is stop, at
the same time the inverter output Releasing command to contactor (TC) and
stop signal of elevator. At this time, one operation cycle is over.
Note:
Detailed functions of multi-step speed mode are as follows: The logics are the same
with controlling contactor and brake signal, controller can control the brake with
elevator running 1(LR1) and holding-brake output.
Detailed functions of multi-step speed mode are as follows:
Function
Code
Name
Recommendation
setting
Remark
P0.00 Speed control mode
1 Vector control with PG
P0.01
Run command
source
1 Terminal control
P0.02
Rated speed of
elevator
1.500m/s User setting
P0.03
Speed command
source
3 Multi-step Speed
P0.04
Maximum output
frequency
50.00Hz User setting
P1.00 Multi-step Speed 0
0
Setting parameters
according to user’s needs,
and Multi-step speed 0 is set
to be 0m/s
P1.01 Multi-step Speed 1
Re-flat layer speed
P1.02 Multi-step Speed 2
Creeping speed
P1.03 Multi-step Speed 3
Urgency speed
P1.04 Multi-step Speed 4
Reserved
