CHV180 series frequency inverter special for elevator Appendix A
.116.
Function
Code
Name
Recommendation
setting
Remark
P2.06 Motor rated speed
Tractor nameplate
P2.07 Motor rated voltage
Tractor nameplate
P2.08 Motor rated current
Tractor nameplate
P3 group
Vector control
Recommendation
setting
Set by running effect
P4.00
Encoder type
selection
Affirm the type of
encoder
Set by encoder
P4.01
Number of pulse of
encoder
P4.02 Encoder direction
0 Set by result of debugging
P5.02 S1 terminal function
1 Up run (FWD)
P5.03 S2 terminal function
2 Down run(REV)
P5.04 S3 terminal function
8
Multi-step Speed reference
1(MS1)
P5.05 S4 terminal function
9
Multi-step Speed reference
2(MS2)
P5.06 S5 terminal function
3 Overhaul run(EXM)
P5.07 S6 terminal function
19
Inverter enable(ENA)
P5.08 S7 terminal function
10
Multi-step Speed reference
3(MS3)
P5.09 S8 terminal function
17 Contractor feedback (TB)
P5.10 S9 terminal function
18
Contracting brake
feedback(FB)
P5.11
S10 terminal
function
6 Fault reset(RET)
P6.04 Relay 1 output 4
Fault output(EO)
P6.05 Relay 2 output 7
Contracting brake
control(FC)
P6.06 Relay 3 output 8
Relay control(TC)
P8.04
Brake and contactor
control selection
3
Inverter control contracting
brake and contactor
P8.05 selection of brake 0.0s
