CHV180 series frequency inverter special for elevator Detailed function description
.35.
and return to the stop state.
e. During the autotuning, press the >>/SHIFT, it can switch keypad to display parameters,
and monitor the running state. Press the STOP/RST,it will stop the autotuning.
P0.01=0(Keypad control)
P2.00=1
P4.00=1 P4.00=2
P2.00=0
P4.00=0
Motor type
Encoder type
Input encoder type
P4.01
(P2.04~P2.08)
Input motor
parameters
Setting P0.08=1,
press "RUN"
Display "TUN-0"
Display "TUN-1"
Display "-END-"
Asynchronous
machine
Synchronous
machine
Gain
SIN/COS
UVW
Autotuning starts
The step 0 of autotuning
The step 1 of autotuning
Autotuning end
Note: If it reports fault of PCDE in the process of autotuning, please modify
The direction of encoder. Please check the wiring of encoder when there are other faults
related to encoder.
Aototuning of synchronous motor’s result is the parameters (P4.03 and P4.07~P4.09)
related magnectic pole. Aototuning of asynchronous motor’s result is the parameters
(P2.10~P2.14).
2: Static autotuning:
When performing static autotuning, If it is difficult to disconnect the load, static autotuning
is recommended,and choose the right motor style, input parameters (P2.04~P2.08) on
the nameplate of motor. For asynchronous motor, the stator resistor, rotor resistor,
