In the running state, CHV180 series inverters can display 5 parameters: running speed,
set speed, bus voltage, output voltage and output current.
The displayings of other parameters are determined by the function code. If Bit is 0, the
parameter will not be displayed; If Bit is 1, the parameter will be displayed. Press 》
/SHIFT to scroll through these parameters in right order. Setting function code P7.06,
binary numbers should be changed into hex numbers.
The display content corresponding to each bit of P7.06 is described in the following:
BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
AI2 AI1
Output
terminal
state
Input
terminal
state
Output
torque
Note: I/O terminal state is displayed in decimal. For details, please refer to
description of P7.19 and P7.20.
Function
Code
Name Description
Setting
Range
Factory
Setting
P7.07 determines the display parameters in stop state. The setting method is similar with
P7.06.
The display content corresponding to each bit of P7.07 is described in the following
table:
