CHV180 series frequency inverter special for elevator General
.8.
Extension
Card
Description
3. Offer frequency division output, the frequency division factor
can be selected by dial switch.
SIN/COS PG
Card
(synchronous
motor)
Receive high-speed pulse from encoder to realize high- accuracy
close-loop vector control.
SIN/COS PG Card compatible with SIN/COS encoder.
Frequency division is 1, which can not be changed.
UVW PG Card
(synchronous
motor)
Receive high-speed pulse from encoder to realize high- accuracy
close-loop vector control.
UVW PG Card compatible with UVW encoder. Offer frequency
division output, the frequency-division factor can be selected by
dial switch.
I/O Extension
Card
Offer more input/output terminals to enhance the external function
of inverter. RS485 port is available.
Please refer to chapter 7 for more detailed information.
