User manual of EC160 elevator intelligent integrated machine Function parameters
132
Function
code
Instruction Setting range【default value】 Remarks
F0_20 Filter coefficient of stop curve 0~65535【0】
Not modify
in running
0: disable
Valid range 1~255 (generally unnecessary to set the value, modifiable when the elevator shakes
after stopping in door area)
Function
code
Instruction Setting range【default value】 Remarks
F0_21 Peristaltic landing distance 0~65535【0】
Not modify
in running
0: disable
Valid range 10~200mm (modifiable when the asynchronous motor drives by pulley or long floor
rope slides)
Function
code
Instruction Setting range【default value】 Remarks
F0_22 UPS application 0~65535【0】
Not modify
in running
0: 220V power supply (The switching of drive power supply is controlled by Y6. Set KPWR input
to normally closed logic. Detect UPS output feedback and bus voltage. After leveling open delay,
disconnect Y6.)
1: 380V power supply (The switching of drive power supply is controlled by UPS itself. UPS bus
voltage detection is unnecessary. After leveling open delay, output Y6, KPWR input optional.)
When using pre-opening or peristaltic landing, Y6 is forced as
pre-opening request prior to output in UPS mode. In the case, select
the 2
nd
UPS application, that is, the switching of power supply of the
integrated machine is controlled by UPS itself or peripheral lines. If
necessary, the peripheral lines control the disconnection of power
supply after UPS returns to leveling.
