INVT EC160

User manual of EC160 elevator intelligent integrated machine Debugging tools
51
Function
code
Name Detailed instruction of parameters
Default
value
P2.02
Rated frequency of the
motor
3.00Hz~400.00 50.00
P2.03
Rated speed of the
motor
1~30000rpm 1440
P2.04
Rated voltage of the
motor
0~460V 380
P2.05
Rated current of the
motor
0.1~1000.0A
Depend on
model
P2.06
Stator resistance of the
motor
0.001~65.535Ω
Depend on
model
P2.07
Rotor resistance of the
motor
0.001~65.535Ω
Depend on
model
P2.08 Inductance of the motor 0.1~6553.5mH
Depend on
model
P2.09
Mutual inductance of
the motor
0.1~6553.5mH
Depend on
model
P2.10
Non-load current of the
motor
0.01~655.35A
Depend on
model
P2.11 Reserved 0~65535 0
P2.12 Reserved 0~65535 0
P3 Group Encoder parameters
P3.00 Encoder type selection
0: Incremental encoder
1: SIN/COS encoder
2: UVW encoder
3: ENDAT encoder
1
P3.01 Encoder resolution 1~10000 2048
P3.02 Encoder direction
0: Forward input
1: Reverse input
0
P3.03
Disconnection
detection time of the
encoder at low speed
0.1~10.0s
0.0: No detection
1.0
