INVT EC160

User manual of EC160 elevator intelligent integrated machine Debugging tools
52
Function
code
Name Detailed instruction of parameters
Default
value
P3.04
Disconnection
detection time of the
encoder at high speed
0.1~10.0s
0.0: No detection
1.0
P3.05
Reverse detection time
of the encoder
0.1~10.0s
0.0: No detection
1.0
P3.06
Magnetic pole position
amplitude gain
0.50~1.50 1.00
P3.07
Magnetic pole bias of C
phase
0~9999 395
P3.08
Magnetic pole bias of D
phase
0~9999 395
P3.09
Initial position of the
magnetic pole
0.00~360.00 0.00
P3.10
Static identification
current
10.0%~150.0% 50.0
P3.11
Pulse counting
direction
0~7
0: Do not change
2: Reverse for the synchronous motor
4: Reverse for the asynchronous motor
0
P3.12
CD phase line of 1387
encoder
0~65535
0: CD phase forward detection
1: CD phase reverse detection
0
P4 Group Running comfortability
P4.00
ASR low speed
proportional gain
0~100 20
P4.01
ASR low speed integral
time
0.01~10.00s 0.5
P4.02
Speed detection low
speed filter times
0~8 0
P4.03
Switch low point
frequency
0.00Hz~P4.07 2.00
