INVT GD100-0R4G-SS2-PV User Manual

Goodrive100-PV series solar pumping inverters Function parameters
-31-
Function
code
Name
Detailed illustration of parameters
Default
Modify
motor
by vectors which
directly impact the
features.
Note: Users cannot
modify the parameters
freely.
P02.09
Mutual inductance
of asynchronous
motor
0.1~6553.5mH
Depend
on model
○
P02.10
Non-load current
of asynchronous
motor
0.1~6553.5A
Depend
on model
○
P04 Group SVPWM control
P04.00
V/F curve setting
These function codes define the V/F curve
of GD100-PV series motor 1 to meet the
need of different loads.
0: Straight line V/F curve; applying to the
constant torque load
1: Multi-dots V/F curve
2: 1.3th power low torque V/F curve
3: 1.7th power low torque V/F curve
4: 2.0th power low torque V/F curve
Curves 2~4 apply to the torque loads such
as fans and water pumps. Users can
adjust according to the features of the
loads to get the best performance.
5: Customized V/F(V/F separation); in this
mode, V can be separated from f and f
can be adjusted through the frequency
given channel set by P00.06 or the
voltage given channel set by P04.27 to
change the feature of the curve.
Note: V
b
in the below picture is the motor
rated voltage and f
b
is the motor rated
4
◎
