INVT GD100-0R4G-SS2-PV User Manual

Goodrive100-PV series solar pumping inverters Function parameters
-34-
Function
code
Name
Detailed illustration of parameters
Default
Modify
motor1) or P04.05~P02.16(rated
frequency of motor1)
Setting range of P04.08: 0.0%~110.0%
(rated voltage of motor1)
P04.09
V/F slip
compensation gain
This function code is used to compensate
the change of the rotation speed caused
by load during compensation SVPWM
control to improve the rigidity of the motor.
It can be set to the rated slip frequency of
the motor which is counted as below:
△ f=f
b
-n*p/60
Of which, fb is the rated frequency of the
motor, its function code is P02.01; n is the
rated rotating speed of the motor and its
function code is P02.02; p is the pole pair
of the motor. 100.0% corresponds to the
rated slip frequency△ f.
Setting range: 0.0~200.0%
0.0%
○
P04.34
Single-phase drive
mode
Ones: Single-phase motor control mode
0: Disabled; 1: Enabled (The function is
reserved. The control mode of the
single-phase motor is specified by the
external terminal command.)
Tens: Voltage of the secondary winding (V
phase) reverse
0: Not reversed; 1: Reversed
Setting range: 0~0x11
0x00
◎
P04.35
Voltage ratio of V
and U
0.00~2.00
1.40
○
