Goodrive200A inverters Function parameters
57
Function
code
Name Detailed instruction of parameters
Default
value
Modify
P05.50
Lower limit
frequency of
HDI
0.000kHz~P05.52
0.000
kHz
○
P05.51
Correspondin
g setting of
HDI low
frequency
setting
-100.0%~100.0% 0.0% ○
P05.52
Upper limit
frequency of
HDI
P05.50 ~50.00kHz
50.00
kHz
○
P05.53
Correspondin
g setting of
upper limit
frequency of
HDI
-100.0%~100.0% 100.0%
○
P05.54
HDI
frequency
input filter
time
0.000s~10.000s 0.100s
○
P06 Group Output terminals
P06.00
HDO
output
The function selection of the high-speed pulse
output terminals.
0: Open collector pole high speed pulse output:
The Max.pulse frequency is 50.0kHz. See
P06.27~P06.31 for detailed information of the
related functions.
1: Open collector pole output. See P06.02 for
detailed information of the related functions.
0 ◎
P06.01
Y1 output
0:Invalid
1:In operation
2:Forward rotation
3:Reverse rotation
4: Jogging
5:The inverter fault
6:Frequency degree test FDT1
7:Frequency degree test FDT2
8:Frequency arrival
9:Zero speed running
10:Upper limit frequency arrival
0 ○
P06.02
HDO
output
0 ○
P06.03
Relay RO1
output
1 ○
P06.04
Relay RO2
output
5 ○
