Goodrive200A inverters Function parameters
59
Function
code
Name Detailed instruction of parameters
Default
value
Modify
P06.11
RO1
switching-off
delay time
0.000s
○
P06.12
RO2
switching-on
delay time
0.000s
○
P06.13
RO2
switching-off
delay time
0.000s
○
P06.14
AO1 output 0:Running frequency
1:Setting frequency
2:Ramp reference frequency
3:Running rotation speed
4:Output current
(relative to the rated current of the inverter)
5:Output current
(relative to the rated current of the motor)
6:Output voltage
7:Output power
9:Output torque
10:Analog AI1 input value (The inverter(≤15kW)
can be set by the analog potentiometer on the
keypad and AI1 setting is not available for the
device which is 18.5kW or higer than 18.5 kW)
11:Analog AI2 input value
12:Analog AI3 input value
13:High speed pulse HDI input value
14:MODBUS communication set value 1
15:MODBUS communication set value 2
22: Torque current
(relative to the rated current of the motor)
23: Ramp reference frequency(with sign)
0 ○
P06.15
AO2 output 0 ○
P06.16
HDO
high-speed
pulse output
selection
0 ○
P06.17
L
ower limit of
AO1 output
The above function codes define the relative
relationship between the output value and analog
output. When the output value exceeds the range
of set maximum or minimum output, it will count
according to the low-limit or upper-limit output.
When the analog output is current output, 1mA
equals to 0.5V.
In different cases, the corresponding analog
0.0% ○
P06.18
Correspondin
g AO1
output
to the lower
limit
0.00V
○
P06.19
Upper limit of
AO1 output
100.0%
○
