INVT Goodrive10 Series User Manual

Goodrive10 Series Mini VFD Function parameters
-52-
Function
code
Name
Description
Default
Modify
P07.07
Parameter
selection of
stopping state
0x0000–0xFFFF
BIT0: Set frequency (Hz on, frequency flickering
slowly)
BIT1: Bus voltage (V on)
BIT2: Input terminal state
BIT3: Output terminal state
BIT4: PID reference (% flickering)
BIT5: PID feedback (% on)
BIT7: AI1 (V on)
BIT8: AI2 (V on)
BIT11: Current step of multi-step speed
BIT12: Pulse counting
0x00FF
○
P07.08
Frequency
display
coefficient
0.01–10.00
Displayed frequency = Running frequency ×
P07.08
1.00
○
P07.09
Rotation
speed
coefficient
0.1–999.9%
Mechanical rotation speed =120 × displayed
running frequency × P07.09/motor pole pairs
100.0%
○
P07.10
Linear speed
displayed
coefficient
0.1–999.9%
Linear speed = Mechanical rotation speed ×
P07.10
1.0%
○
P07.11
Reserved
●
P07.12
Inverter
module
temperature
-20.0–120.0°C
●
P07.13
Control board
software
version
1.00–655.35
●
P07.14
Local
accumulative
running time
0–65535h
●
P07.18
Rated power
of the VFD
0.4–3000.0kW
●
P07.19
Rated voltage
of the VFD
50–1200V
●
P07.20
Rated current
of the VFD
0.1–6000.0A
●
