Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-75-
Function
code
Name
Description
Default
value
Modify
LED tens: frequency control selection
0: Only valid when P00.06=0 or P00.07=0
1: Valid for all frequency setting manners
2: Invalid for multi-step speed when multi-step
speed has the priority
LED hundreds: action selection during stop
0: Setting is valid
1: Valid during running, cleared after stop
2: Valid during running, cleared after receiving
the stop command
LED thousands: integral function of ∧/∨ keys
and analog potentiometer
0: The integral function is valid
1: The integral function is invalid
P08.44
UP/DOWN
terminal control
setting
0x000–0x221
LED ones: terminal setting selection
0: UP/DOWN terminal setting is valid
1: UP/DOWN terminal setting is invalid
LED tens: frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency setting means
2: Invalid for multi-step speed when multi-step
speed has the priority
LED hundreds: action selection when stop
0: Setting is valid
1: Valid during running, cleared after stop
2: Valid during running, cleared after receiving
the stop command
0x000
○
P08.45
UP terminal
frequency
increment
integral rate
0.01–50.00s
0.50s
○
P08.46
DOWN terminal
frequency
decrement
integral rate
0.01–50.00 s
0.50s
○
