Page #82 background imageLoading...
Page #82 background image
Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-77-
Function
code
Name
Description
Default
value
Modify
Brake immediately after the stop command. It
does not need to wait until the magnetic flux
weakens.
The cooling is better. The current of the stator
other than the rotor increases during magnetic
flux braking, while the cooling of the stator is
more effective than the rotor.
P08.51
Current
regulation
coefficient on
input side
This function code is used to adjust the current
display value on the AC input side.
Setting range: 0.001.00
0.56
P09 PID control
P09.00
PID reference
source
When the frequency command selection
(P00.06, P00.07) is 7 or the voltage setting
channel selection (P04.27) is 6, the VFD is
process PID controlled.
This function code determines the target given
channel during the PID process.
0: Keypad (P09.01)
1: Reserved
2: AI2
3: AI3
4: Reserved
5: Multi-step speed
6: MODBUS communication
79: Reserved
The set target of process PID is a relative value,
for which 100% equals 100% of the feedback
signal of the controlled system.
The system always calculates a related value
(0100.0%).
Note: Multi-step speed setting can be realized
by setting P10.
0
P09.01
PID reference
preset through
keypad
This function code is mandatory when P09.00=0.
The base value of this function code is the
feedback of the system.
Setting range: -100.0%100.0%
0.0%
