INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-88-
Function
code
Name
Description
Default
value
Modify
0: The VFD continues to work after OL/UL
pre-alarm
1: The VFD continues to work after underload
pre-alarm and stops running upon an overload
fault
2: The VFD continues to work after overload
pre-alarm and stops running upon an underload
fault
3. The VFD stops when OL/UL occurred.
LED hundreds :
0: Detect all the time
1: Detect during constant speed running
LED thousands: Overload integral function
selection
0: Overload integral is invalid
1: Overload integral is valid
P11.09 setting range: P11.11–200%
P11.10 setting range: 0.1–3600.0s
P11.11
Underload
pre-alarm
detection
threshold
If the output current of the VFD or motor is less
than P11.11 and the lasting time exceeds
P11.12, the underload alarm signal is output.
P11.11 setting range: 0– P11.09
P11.12 setting range: 0.1–3600.0s
50%
○
P11.12
Underload
pre-alarm
detection time
1.0s
○
P11.13
Fault output
terminal action
selection at a
fault
This function code is used to select the action of
fault output terminals on undervoltage and fault
reset.
0x00–0x11
LED ones:
0: Act at an undervoltage fault
1: Not act at an undervoltage fault
LED tens:
0: Act during the automatic reset period
1: Not act during the automatic reset period
0x00
○
