INVT iMars MG Series User Manual

INVT iMars MG series grid-tied solar inverters Monitoring communication
Optional accessories Inverter port Port of upper PC
Ethernet converter RS485/EXT RJ45 plug
WiFi converter RS485/EXT WiFi signal
Please download the connection instruction, operation manual and commissioning tools on
website www.invt-solar.com.
Note: the optional accessories are not standard-configured.
6.2.1 WiFi200 converter
6.2.1.1 WiFi200 Product Introduction
iMars WiFi200 communication converter has 1 RS485 and 1 WiFi communication port for the data
transmission. This product is based on the embedded module with general serial port which meets
the network standard, has built-in TCP/IP protocol stack for the transformation between the user
serial port and WiFi port. The traditional serial device can transfer the data through Internet without
any configuration modification. WiFi200 provides a complete and rapid solution of data
transmission for serial devices.
Table 6-3 iMars WiFi200 has the following features:
Interface Parameters function
RS485
interface
1.
Automatic control of data flow, automatic identification and
transmission direction of control data and no handshake signal
is needed
2. Transmission speed 300~115200Baud
3. Up to 32 devices of RS485
4. the maximum transmission distance 1200m
5. Flow indicator
6. Half duplex mode
WiFi
interface
1. Support data exchange between RS485 - WiFi interface
2. Meet the 802.11 b/g/n wireless standard
3. Wireless network AP/STA
4. Security mechanismWEP/WPA-PSK/WPA2-PSK/WAPI
5. Barrier-free transmission distance 100m
- 53 -
