IPG PHOTONICS | PULSE SHAPING SOFTWARE OPTION
Pulse Sequence Activation
1. After storing a pulse sequence to the laser, make sure the E-stop button is released on the laser
and then press the green button to turn on the power supply
Note: Both Analog and Modulation modes must be set to “Off” to correctly configure the pulse
sequence mode. To change them for select Pulse Menu->Pulse Setting
2. On the laser touch-screen, select Pulse Menu->Pulse Setting->Waveform Mode
3. Toggle Waveform Pulse Mode to Enabled, and Pulse Sequence Selected, then use the Up/Down
arrows to select a specific pulse sequence.
4. Pulse Sequence Information/Preview (Optional)
5. To get information about the pulse sequence, click on the pulse browser button, the information
page appears, you can use the arrows to scroll thru all available pages. Click anywhere in the text
space to go to the Preview page, here you can see the shape of the pulses in the sequence; use
the arrows to see the entire page. Click Return twice to go back to the Waveform page.
It is important to configure the laser with the selected pulse sequence (once) before usage.
6. Click Configure & Return. After the configuration is complete, click Return twice to go back to the
main page. Then click Emission, and then click OK to confirm and start countdown. The selected
pulse will be emitted after the countdown. Click Emission again to clear the status, this will also stop
a pulse sequence if it is set to infinite repeats.
Remote Control Interface
This interface is designed to provide remote control for PSG users, it is focused around the pulse-
shaping feature and it not meant to be a comprehensive control utility. Note: This interface will
work simultaneously with the touch-screen panel.
1. To start the interface, select Remote Control from the top menu Use the Setup panel to enable the
waveform (pulse) mode, select the pulse or sequence mode, select a pulse or sequence then
configure the laser.
