YLR-SERIES USER GUIDE
IPG PHOTONICS | SERVICE
77
14. Figure 18).
CAUTION: It is hereby stated that damage to the fiber connector can occur due to mishandling,
the use of incorrect cleaning procedures, or chemicals for cleaning. This is not covered by the
warranty.
Figure 17: Fiber End-face Cleaning
Start to clean with even pressure.
Drag in only one direction.
