#31
www.istorage-uk.com
iStorage datAshur PRO
2
®
User Manual v2.1
40. How to check whether the Drive is Removable or Local Disk
To check the disk enumeration setting, first enter the “Admin Mode” as described in section 5. Once the drive is in Admin
Mode (solid BLUE LED) proceed with the following steps.
1. In Admin mode press and hold down both
SHIFT ( ) + 1 buttons
Solid BLUE LED will change to blinking GREEN
and BLUE LEDs
2. Press the KEY ( ) button and the following happens;
• If datAshur PRO
2
is configured as Local Disk, the following happens;
a. All LED’s (RED, GREEN & BLUE) become solid for 1 second.
b. GREEN LED blinks once.
c. All LED’s (RED, GREEN & BLUE) become solid for 1 second.
d. LEDs return to solid BLUE
• If datAshur PRO
2
is configured as Removable Disk, the following happens;
a. All LED’s (RED, GREEN & BLUE) become solid for 1 second.
b. All LEDs are off
c. All LED’s (RED, GREEN & BLUE) become solid for 1 second.
d. LEDs return to solid BLUE
Note: When the datAshur PRO
2
is in Admin Mode, the BLUE LED will remain on and solid for 30 seconds only,
during which time the drive can accept instructions via the keypad allowing it to be configured with a host of security
features. If no key event happens within 30 seconds, the datAshur PRO
2
will exit Admin mode automatically - the
solid BLUE LED switches to a solid RED LED which then fades out to the Idle state (all LEDs off).
To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED which then fades out to the Idle state. To access the drive contents
(data), the datAshur PRO
2
must first be in the idle state (all LEDs off) before an Admin/User PIN can be entered.
