00 – 16 SERVICE INFORMATION
FAULTY MESHING OF PINION AND RING GEAR
CHECK IF BATTERY VOLTAGE IS PRESENT AT
MAGNETIC SWITCH TERMINAL “S” WHEN
STARTER SWITCH IS TURNED TO “START (ST)”
YES
EXTREME WEAR OF
PINION AND RING
GEAR
REPAIR OR REPLACE
STARTER, REPLACE
RING GEAR
OR
NO
UNDER THIS CONDITION, CHECK IF VOLTAGE
OF CONNECTOR 3BW ON MAGNETIC SWITCH
OF RESTART RELAY IS NORMAL
YES NO
DISCONNECTION OR
FAULTY CONNECTION
BETWEEN STARTER
SWITCH AND MAGNETIC
SWITCH
CHECK IF VOLTAGE IS
PRESENT AT WIRING
CONNECTOR 3BW ON
STARTER SWITCH OF
RESTART RELAY
STARTER SLIDING
RESISTANCE IS
LARGE
REPAIR OR REPLACE
STARTER
FAULTY CONNECTION OF
STARTER SWITCH
DISCONNECTION OR
FAULTY CONNECTION
BETWEEN STARTER
SWITCH AND BATTERY
REPLACE STARTER
SWITCH
REPAIR
YES NO
REPAIR
