6A1 – 108 4JB1/4JB1T/4JB1TC/4JG2 - ENGINE
'
Front Exhaust Pipe
Front Exhaust Pipe Bolts Torque N∙m (kg∙m/lb∙ft)
37 (3.8/27)
&
Exhaust Brake Assembly
Exhaust Brake Bolts Torque N∙m (kg∙m/lb∙ft)
1 7(1.8/12)
%
Clutch Slave Cylinder
Slave Cylinder Bolts Torque N∙m (kg∙m/lb∙ft)
19 (1.9/14)
• Perform slave cylinder adjustment before installation
of the return spring.
a) Loosen the lock nut of the push rod.
b) Turn the adjust nut until it reaches the shift fork.
c) Back off the adjust nut 1.5 turns. (shift fork free
play Approximately 2 mm/0.1 in).
d) Tighten the lock nut.
Push Rod Lock Nut Torque N∙m (kg∙m/lb∙ft)
16 (1.6/12)
$
Shift Cable and Select Cable
#
Wiring Connector
• Color of Connector
Back-up Light Switch: Brown
Neutral Switch: Gray
"
Parking Brake Cable
!
Propeller Shaft
• Line up reference mark.
Propeller Shaft Nuts Torque N∙m (kg∙m/lb∙ft)
66 (6.7/48)
• Connect the battery ground cable
• Pour coolant
• Start the engine and check coolant leakage
To Next Page
