Advanced Function
Cut Off
I
Set the cut off current.
Cut Off
Q
Set the cut off capacity.
During editing, the instrument would automatically return to the main
interface if there is no operation for a long period.
operation steps:
1. Press [Shift]+[I-set](Function) to enter Function menu.
2. Rotate the knob to select Battery and press [Enter] to confirm.
3. Rotate the knob to select Run, Recall, Edit in turn.
Run Recall Edit
4. Select different functions for setting, for detailed operation about battery file
editing, recalling and running, please refers to following introduction.
The running, recalling and editing of List function are mutual
prerequisites. When the system has no existed battery test file, it is
necessary to edit battery test file, recall battery test file, and finally run the
recalled battery test file.
Edit Battery Test File
1. Under the battery test interface, select the Edit and enter to the edit file
menu.
2. Select the desired file number to edit. The maximum file number is 10.
Edit File = 1/10
3. Setting the parameters in turn. Press [Enter] to confirm.
1：Disch I = 1.00A
2：Disch Time = 60S
3：Cut Off V = 8.00V
4：Cut Off I = 5.00A
5: Cut Off Q = 10AH
Copyright © Itech Electronic Co., Ltd.
55
