Advanced Function
4. After setting press [Esc] to exit.
Recall and view battery test file
1. In the battery test function setting interface, select the Recall and enter to
the edit file menu.
2. Rotate the knob to set the number of List file to be recalled. At maximum of
10 battery test files can be recalled in this instrument.
Recall Batt = 1/10
When the selected number is empty, the interface would prompt that the
recalled file is empty. The user needs to select the file again or return and
enter the Edit menu for editing.
3. After successful recall, the user can view the setting information of the
existing battery test file. The following parameters can only be viewed, and
cannot be edited. To modify them, please return and enter the Edit menu to
select the corresponding file number for editing.
1：Disch I = 1.00A
2：Disch Time = 60S
3：Cut Off V = 8.00V
4：Cut Off I = 5.00A
5: Cut Off Q = 10AH
4. Press [Esc] key, and exit the existing page.
Run Battery test file
After the battery test files are edited, the user needs to select Run to enable the
battery test function and return to the main interface to trigger the running.
12.000V 10.000A
00:00:01 0.00Ah
• First line: The voltage and current meter value.
• Second line: testing time and battery capacity.
When testing, as long as any one of the cut-off conditions is met, the test stops.
Stop running and re-running
During the running of battery test file, press [Shift]+[I-set](Function) composite
key, and the instrument interface displays the running state control interface of
the existing file. The user can press Stop to stop existing test and turn off the
List function. Or, press Reset to restart a new test.
Copyright © Itech Electronic Co., Ltd.
