Power Supply Function

• When connecting the DUT (battery/capacitor), do not short-circuit

the battery/capacitor.

• When connecting the DUT (battery/capacitor), it is recommended

that you purchase the IT-E165A anti-reverse connection and anti-

spark module to prevent the battery/capacitor reverse connection

that may cause damage to the instrument and spark during the bat-

tery/capacitor wiring; When there is no external auxiliary equipment

connected to prevent reverse connection and anti-spark function,

please pay attention to the safety of the wiring, and be careful not

to reverse the battery/capacitor connection, reverse connection will

cause damage to the instrument.

• Before performing the battery test, you need to connect the Sense

cables to both ends of the battery. If the Sense cables are not con-

nected, the instrument cannot detect the Sense voltage and prompt

“Wait Power Link”, which will prevent the battery test from

continuing.

BATTERY

Battery charging test function

Run

Indicates that the battery test mode is entered and

waits to trigger the running of the currently edited bat-

tery test file.

Edit

Edit the battery charging test file.

Charge V

Set the voltage value of the bat-

tery charging test.

Charge I

Set the current value of the bat-

tery charging test.

Charge Time Set the battery charging time.

Cut Off Voltage Battery test cut-off voltage

Cut Off Current

Battery test cut-off current

Cut Off Capacity Battery test cut-off capacity

1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-

ter the function menu.

2. Use knob to select 2.BATTERY: Off and press [Enter].
