Power Supply Function

The interface is displayed as follows:

FUNCTION BATTERY

Run Edit

3. Press the Left/Right key to select Edit and press [Enter].

4. Set the charging voltage (Charge V), charging current (Charge I) and the

other parameters, and then press [Enter] to confirm.

After the parameter setting is completed, the interface returns to the Battery

function main interface and displays as follows:

FUNCTION BATTERY

Run Edit

5. Press the Left/Right key to select Run and press [Enter] to run the battery

test.

This product supports Sense anti-reverse function. If you reverse the

Sense cables, the VFD will display a negative voltage value, and you can-

not turn on the output at this time. It can only be turned on after the cables

are properly connected.

6. Based on the selected trigger method, perform the trigger operation.

The trigger method of the battery test is consistent with the trigger method

of the List function, that is, the List trigger source is also effective for the

Battery function.

If you want to stop running during the battery test, you can do the following:

Press the composite keys [Shift]+[I-set] (Function) on the front panel to enter

the function menu.

At this point, the interface will prompt whether to stop the running of the Func-

tion, you can press the Left/Right key to select Stop, then the running will be

stopped, and the Function menu item will be displayed, you can re-enter the

Function menu for editing; if Reset is selected, it means that it will not stop run-

ning, it will return to the main interface, and run Battery again.
