Power Supply Function
Table Indicates a user-defined 4096-point I-V data table. This
menu item is reserved and can only be used in PV SAS
software sold separately. This function cannot be used in
the VFD screen.
Filter Filter the input voltage of the instrument to reduce
interference.
Low The filtering speed is low speed.
Mid The filtering speed is medium speed.
Fast The filtering speed is high speed.
Edit Static PV Curve
You can edit the static PV curve and save it inside the instrument (up to 100
curve records can be saved), or you can customize the editing of the PV curve
(up to 1 can be saved).
• Curve
The steps to edit a static curve locally on the instrument are as follows:
1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to
enter the function menu.
2. Use knob or Up/Down key to select 4. SAS: Off and press [Enter].
3. Press the Left/Right key to select Static and press [Enter].
4. Press the Left/Right key to select Curve and press [Enter].
5. Press the Left/Right key to select Edit and press [Enter].
6. Set the Pmp, Vmp and Formula in turns, and press [Enter].
7. Set the saved file name and press [Enter].
– Also you can set the filter speed in SAS→Filter according to the ac-
tual test needs.
– After the above Curve parameters are set completely, you can press
[Esc] until you return to the SAS main interface and select Run to
trigger the current edited Curve file to run.
• User-defined
The steps to edit a custom curve are as follows:
1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to
enter the function menu.
