Function and Features
Over-Temperature Coefficient protection
When internal power device of instrument is higher than about 90 °C, the
instrument is under Temperature Coefficient protection. At this time, the
instrument will automatically be OFF and VFD will display “Over Temperature
Coefficient”.
Power down protection
With power-down protection, when the instrument power supply is switched off
and the instrument detects power-down status, the instrument will immediately
execute output switch-off and the instrument interface will display “power-
down”.
Under Voltage Protection
When internal voltage is low due to internal fault or when AC input voltage is
low, the instrument will initiate the under-voltage protection. Or when 110V AC
power supply is connected, the instrument output function is limited. When the
set output power exceeds limit value, the instrument will also initiate under-
voltage protection status. In the case of under-voltage protection, the
instrument interface will prompt “Under Voltage Prot”.
Sense Reverse Protection
The instrument defaults to provide sense reverse protection. When the output
state is ON and the difference between output terminal voltage and sense
remote voltage exceeds the specified voltage, sense reverse protection will be
enabled after 500ms. The power supply output will be immediately switched to
Off and the buzzer will sound if the sense terminals are reversed. The display
screen will display “Sense Reverse Prot”. Press [Esc] to clean the protection.
When the power source is in Sense Reverse Protection state, you should check
the whether the polarities are connected reversely or not firstly. When the
polarities connect correctly, please press [On/Off] button. Then the unit could
have a output voltage again.
The voltage difference between output terminal and remote sense terminal of
each model is not the same. The detailed value is shown in the next table.
When the remote sense terminal is connected reversely, the maximum voltage
will not exceed the sum of set voltage and the difference voltage.
IT6512C~IT6592C 5V
IT6513C~IT6593C 5V
IT6514C~IT6594C 7V
Copyright © Itech Electronic Co., Ltd.
37
