1.3 Keyboard Introduction
The keyboard introduction of IT8000 series Regenerative DC Electronic Load is
shown as follows.
Keys Description
[On/Off] Turn the load input on or off. When lit, indicates that the input
is enabled or on.
[V-set] Set the input voltage value
[I-set] Set the input current value
[P-set] Set the input power value
[R-set] Set the resistance value
[Shift] Composite key, combined with other keys to realize functions
marked above keys.
[Esc] Press this key to exit the current operation interface.
[0]-[9] Numeric keys
+/– Positive and negative signs
. Decimal point
Left / Right
navigation
keys
The left and right navigation keys are used to adjust the cur-
sor to the specified position or scrolls pages to view menu
items.
Up / Down
navigation
keys
The up and down navigation keys are used to scroll page up
and down to view menu items.
[Enter] Operation confirmation key
