Load Function

After the List file finishes running, the system determines whether to re-

turn to the working mode before the List is run according to the Normal or

Last option you selected.

Stop Running the List Program

When the List program is running, if you need to stop running, you can do the

following: Press the composite keys [Shift]+[I-set] (Function) on the front panel

to enter the function menu.

At this point, the interface will prompt whether to stop the running of the Func-

tion, you can press the Left/Right key to select Stop, then the current running

will be stopped, and the Function menu item will be displayed, you can re-enter

the Function menu for editing; if Reset is selected, it means to stop the present

running and return to the main interface to wait for the next trigger operation.

4.2.2 Battery Discharging Test Function

The IT8000 series load provides the battery discharging test function, which is

suitable for discharging tests on all types of portable batteries. The user can set

three cut off conditions: cut off voltage, current off capacity and the charging

time. If anyone of the three conditions are satisfied, the test will be interrupted

automatically.

BATTERY

Battery discharging test function

Run

Indicates that the battery test mode is entered and

waits to trigger the running of the currently edited bat-

tery test file.

Edit

Edit the battery discharging test file.

Cut Off Voltage Battery test cut-off voltage

Cut Off Capacity Battery test cut-off capacity

Cut Off Timer

Battery test cut-off time

The operation steps to set the battery discharging test function are as follows.

1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-

ter the function menu.

2. Use knob or Up/Down key to select BATTERY and press [Enter].

The interface is displayed as follows:

BATTERY TEST
