Quick Reference
Composite key [Shift], combined with other keys to realize functions marked
above keys. The detailed functions are listed as follows.
Keys Description
[Shift]+[On/Off]
(Trigger)
Generate a local trigger signal.
[Shift]+[V-set]
(Config)
Enter the Config menu of the load
[Shift]+[I-set]
(Function)
Enter the Function menu of the load
[Shift]+[P-set]
(System)
Enter the System menu
[Shift]+[R-set]
(Protect)
Enter the Protect menu of the load
[Shift]+[1] (Log) Enter the data logging function menu.
[Shift]+[2] (Lock) Turn the keyboard lock on or off.
[Shift]+[3] (Local) Switch remote control mode to local control mode.
[Shift]+[0] (Recall) Returns the instrument to the specified setup.
[Shift]+[.] (Short) Short circuit function key
[Shift]+[+/–]
(Save)
Save the common parameter settings.
1.4 Push-on Knob
The IT8000 series Regenerative DC Electronic Load provides a knob on the
front panel as shown in the next figure.
The functions of the posh-on knob is described as follows.
• Adjust the value setting
• Select menu item
Copyright © Itech Electronic Co., Ltd.
5
