ITech IT8000 Series User Manual

Quick Reference
IO-2. Ps, Not-Invert
Function setting of pin 2
IO-3. Off-Status, Not-
Invert
Function setting of pin 3
IO-4. Ext-Trig, Not-
Invert
Function setting of pin 4
IO-5. INH-Living, Not-
Invert
Function setting of pin 5
IO-6. Sync-On, Not-
Invert
Function setting of pin 6
IO-7. Sync-Off, Not-
Invert
Function setting of pin 7
Ext-Program
External Analog Function. This function is optional. The menu can only
display when corresponding board card is inserted. For details, see
5.12 Analogue Function (Ext-Program) (Optional).
System Reset Select whether to restore the factory default settings or not.
System Info
View the system information. For details, see 5.14 View the System In-
formation (System Info).
AC-Meter
Observe power grid information.
Display Display the current regenerative power value.
Clear Clear the total current regenerative power value.
Disp on timer Screen displays loading time.
On Turn the display on.
Off Turn the display off.
1.9 Options Introduction
The IT8000 series Regenerative DC Electronic Load supports the following two
types of optional accessories (sold separately), the details are as below:
• Communication interface card
– IT-E166: Interface card for GPIB communication. When users need to
use GPIB communication, they can choose to purchase this accessory.
For details, see 2.5.4 GPIB Interface (Optional).
– IT-E167: Interface card that includes RS-232 communication interface,
external analog and other functions.
The accessory has a total of 10 pins, and the details of each pin are as
follows:
Copyright © Itech Electronic Co., Ltd.
15
