Inspection and Installation
Definition of CAN Pins
The definition of CAN pins are as follows.
Pins Description
H CAN_H
L CAN_L
GND Pin 8 (GND) of the digital I/O interface.
Be sure to connect the GND terminal correctly. Using the CAN com-
munication interface when the GND terminal is not connected may re-
sult in unstable communication or damage to the CAN interface.
CAN Configuration
The user needs to configure the CAN interface parameters in the system menu
before using the remote control. The CAN interface parameters are as follows.
Name Description
Baud rate Select the baud rate from the following options: 20k/40k/
50k/80k/100k/125k/150k/200k/250k/400k/500k/1000k
Instrument
Address
Range: 1 – 65535
Prescaler Not settable. Change with Baud rate setting
BS1 Not settable. Change with Baud rate setting
BS2 Not settable. Change with Baud rate setting
The operation steps are as follows.
1. Press the composite keys [Shift]+[P-set] (System) on the front panel to en-
ter the system menu.
2. Rotate the knob or press the Up/Down key to select I/O and press [Enter].
3. Press the Left/Right key to select CAN and press [Enter].
4. Set the baud rate, address and other parameters, press [Enter].
Copyright © Itech Electronic Co., Ltd.
36
